MP-1B Metallographic Grinding and Polishing Machine (New)
MP-1B Metallographic Grinding and Polishing Machine (New)
MP-1B Metallographic Grinding and Polishing Machine (New)

MP-1B Metallographic Grinding and Polishing Machine (New)

Name:MP-1B Metallographic Grinding and Polishing Machine (New)
Details : Production Instruction

MP-1B stepless speed test grinding and polishing machine for double disc type machine, suitable for metallographic pre-grinding, grinding and polishing operation. The operation of the inverter, can be directly obtained speed from 50 to 1000 RPM, so as to make the machine more widespread application.It is an indispensable equipment in making metallographic specimen.

Overview of Structural Features

The machine with a cooling device can cool the specimen in the pre-grinding, to prevent overheating and damaging of the specimen microstructure. The machine has two disc, left for the pre-grinding, grinding,right disc for polishing . The machine not only can do light grinding, coarse grinding, semi fine grinding, fine grinding, but also can do precision polishing.

This machine can be used by two people at the same time. It is an ideal sample preparation equipment for factories, research institutes and laboratories of colleges and Universities

Technical Parameters

Operation Voltage

220V 50HZ

Dia. Of Dis

Φ250mm(Φ203mm Customizable)

Rotation Speed

50-1000RPM

Dia. Of Abrasive paper

Ø 230mm

Motor

YSS7124、550W、

Dimension

730*450*370 mm

Weight

45kg
